Mid Series with Pneumatic Blow Off - VP2X

VP2X series venturi pumps provides both vacuum and blow-off in one pump, using only one compressed air line -- no electricity required. The integrated pneumatic high-speed blow-off on the VP2X pump provides a fixed-duration blow-off, based on the volume of the housing. With the VP2X-ADJ adjustable vacuum pump, you can control the intensity of the blow-off using one fingertip adjustment knob.

  • Fast Response – compact, lightweight and installs close to vacuum point
  • Efficient – minimal air consumption
  • Reliable – operates trouble-free: straight-through design, non-clogging
  • Automatically cleans vacuum lines, no maintenance or downtime
  • Modular design – add sensors & solenoid valves for a complete vacuum system
  • Reliable part detection – factory installed miniature vacuum switches or sensors

VP2X and VP2X-ADJ Standard Pump Specifications:
Body Material: Anodized Aluminum, Nebar, Brass, Buna-N, Vinyl, Nylon, Alloy Steel (For silencer material, see the Accessories Section)
Cartridge Material: Nylon, Buna-N O-ring, (Other materials available, See pages 19-21)
Medium: Filtered (50 Micron) unlubricated, non-corrosive dry gases
Operating Temperature: +32° to ~125° F [0° to ~52°C]
Operating Pressure: 80 PSI [5.5 bar] standard or 60 PSI [4.1 bar] – Consult Factory for other operating pressures
Cycle Rates: Up to 120/min - For higher cycle rates use VP35 Series
Blow-off Response Time: Instantaneous
Orientation: Any position
Blow-off Duration: 100 milliseconds (based on system design)

VP2X and VP2X-ADJ Operating and Installation Requirements:
Cartridge size: C60 (M, H) and C90 (L, M, H) - C100 (L, M, H) and C150 (L, M, H)
Supply Line: 1/4” O.D. [6mm] tube recommended - 3/8” O.D. [10mm] tube recommended
Vacuum Line: 1/4” O.D. [6mm] tube recommended - 3/8” O.D. [10mm] tube recommended
Vacuum Line Filtration: Typically vacuum filters are not required. If desired, Bimba
desired, Bimba recommends – VF-250LPM - Typically vacuum filters are not required. If  desired Bimba recommends VF-250F – See the Accessories Section
Control Valve: 3 way/2 position, minimum orifice - 0.125” ID [3mm]
Mounting Holes: Mounting holes accept 10-32 [M5] screws *Operate valve at <120 cycles/min.
